Iskra K07M-01 Motor Contactor

iskra-k07c

Rating clarification: The German category lists 4.0 kW at 400 V, AC-3, while the detailed table lists 5.5 kW. Please confirm the correct rating for the exact device with Appel before selection.

The contactors are designed for switching electric motors and other resistive, inductive and capacitive loads.
Mounting on a 35 mm DIN rail (EN 60715) or using two screws.



Type K07M-01
Width 45 mm
Alternative version listed in the source catalogue
  • Quick-connect terminals
  • Version with four main contacts (Sp4)
Accessories
Standard coil voltages, 50/60 Hz B7 – 24V    D7 – 42V
E7 – 48V    F7 – 110/125V
M7 – 220/240V    Q7 – 380/415V
R7 – 440V    S7 – 480/520V

Back to Iskra motor contactors

Contact Appel with the type designation and application details for product selection.

Technical data
Standards
IEC/EN 60947-5-1, IEC 60947-4-1, UL 508
Approvals CE, UL, CSA, GOST
Width 45 mm
Rated operational power AC-1 Pe 230V - 7,5 kW 400V - 13 kW 500V - 17,5 690V - 22 kW
Rated operational current AC-1 Ie up to 50°C, open installation up to 60°C, open installation 20A 16A
Rated motor power AC-3 Pe Single-phase 230V - 1,1 kW
Three-phase Three-phase Three-phase Three-phase 230V - 3 kW 400V - 5,5 kW 500V - 5,5 kW 690V - 5,5 kW
Degree of protection IP 20
Weight
0,18 kg
